Trunk Optical Cable Parameters

MPO/MTP trunk cables are high-density, pre-terminated optical assemblies with multi-fiber connectors, designed for ultra-low loss, high-speed backbone networks.

Physical Parameters

Cable Construction: Trunk cables typically use a microcore design, housing arrays of bare fibers (usually 250 µm) within an outer jacket reinforced with aramid yarn for tensile strength . Standard trunks bundle multiple 8, 12, or 16-fiber sub-units, allowing fiber counts from 12 up to 144 or more in a compact diameter . Cable Diameter: The diameter varies with fiber count and bundle configuration. For example, a single MPO-12 cable has a standard diameter of 3.0 mm, while multi-bundle configurations increase proportionally . Jacket Types: Common jacket options include LSZH, OFNR, and OFNP for indoor applications, with compliance to local codes such as CPR Euroclass B2ca in Europe . Connector Type: MPO/MTP connectors are pre-terminated on both ends, often unpinned (female) to mate with pinned cassettes. MPO-16 connectors are increasingly standard for high-density 800G-SR8 backbones . Installation Features: Factory-installed pulling eyes and strain-relief clips protect delicate end-faces during deployment through conduits or raised floors .

Optical Parameters

Fiber Type: Trunks use bend-resistant G.657.A1 single-mode or OM4 multimode fibers . Insertion Loss: Typical insertion loss is as low as 0.35 dB for high-quality assemblies. Ultra-Low Loss (ULL) trunks with ≤0.25 dB are recommended for high-speed networks, while standard loss trunks (≥0.50 dB) are considered obsolete for 400G/800G deployments . Polarity and Base Configuration: Trunks are available in Base-8, Base-12, or Base-16 configurations, with strict polarity management to support parallel optics and high-speed transceivers . Distance and Performance: Multimode fiber trunks support 10 Gbps, 40 Gbps, and 100 Gbps applications over standard distances, compatible with QSFP+, QSFP28, CFP, CXP, QSFP-DD, or OSFP transceivers .

Deployment Considerations

Trunk Length: Calculated by measuring horizontal distance between racks, vertical drops, and adding a service loop (1–3 meters) for future moves or re-termination . Testing and Standards: Pre-terminated trunks are factory-tested according to IEC and TIA standards, ensuring consistent end-to-end link quality and rapid plug-and-play deployment . High-Density Applications: Trunks are widely used in hyperscale data centers, AI/HPC clusters, and enterprise core networks, forming the backbone between main distribution areas (MDAs) and horizontal distribution areas (HDAs), . In summary, MPO/MTP trunk cables combine high fiber density, ultra-low insertion loss, and robust physical construction to support modern high-speed optical networks, with careful attention to connector type, fiber count, jacket material, and deployment planning.
