Which side should the optical cable for the power transmission line be placed on
Optical cables for power transmission lines are typically installed on the top of the towers, either as part of the ground wire (OPGW) or attached to the host conductor (OPAC), to ensure safety, lightning protection, and reliable communication.
Typical Placement
- Optical Ground Wire (OPGW)
- OPGW cables are installed at the top of transmission towers, replacing or integrated with the ground (shield) wire .
- This placement provides lightning protection by grounding strikes and simultaneously allows high-speed data transmission along the power grid .
- The metallic sheath of OPGW protects the optical fibers from environmental and mechanical damage while carrying electrical current safely to the ground .
- Optical Power Attached Cable (OPAC)
- OPAC cables are lashed, wrapped, or clipped directly to the host conductor of the power line .
- They can be installed on phase conductors or ground wires, depending on the system design and voltage level .
- Installation is performed using specialized equipment to maintain proper tension and avoid sagging, and it is usually done by trained personnel due to the high-voltage environment .
- All-Dielectric Self-Supporting (ADSS) Cable
- ADSS cables are non-metallic and can be installed below the power conductors in the telecom space of the tower .
- This placement avoids electrical contact and reduces the risk of coronal discharge, while still providing a secure path for fiber-optic communication .
Safety and Electrical Considerations
- High-voltage lines require careful placement to prevent flashover or dielectric breakdown. Cables should not occupy the space between the conductor and grounded tower to avoid arcing .
- Leakage currents and coronal discharge are more likely near towers and splicing points, so special hardware and handling practices are necessary .
- Proper grounding, tensioning, and protective enclosures at splice points are essential for both mechanical integrity and electrical safety .
Summary
- Top of towers / ground wire: OPGW for lightning protection and communication.
- Attached to host conductor: OPAC, either on phase or ground wires, using wrapping or lashing.
- Below conductors / telecom space: ADSS, avoiding electrical contact and minimizing risk of discharge. Correct placement depends on the cable type, voltage level, and tower design, but the general principle is to maximize safety, minimize electrical interference, and ensure reliable communication.
